Glass material

GG-17

Frame material

stainless steel

Pipe material

304 stainless steel

Movement mode

With brake type universal corner wheel

Reaction bottle volume

50L

Mixing capacity

Minimum no less than 20L, maximum 50L

Sandwich capacity

12L

Flange type oil inlet and outlet

low in and high out

Stirring speed

0-1400rpm

Stirring shaft diameter

12mm

Stirring power

120W1/3

Voltage frequency(V/Hz)

220V/50Hz

Dimensions(mm*mm*mm)

760*560*2450

Package Size(mm*mm*mm)

1720*680*850 0.99方

Package weight（KG）

92

basic configuration

Speed control mode

frequency control, aluminum explosion-proof treatment

Motor configuration

Explosion-proof motors

Speed display mode

LCD digital display

Temperature display mode

PT100 sensor digital display

Sealing method

PTFE component seal, ￠ 50 flange stirring mouth

Condenser

Vertical high efficiency double reflux condenser 120 * 640mm, 40 # mark

Solid feed

￠80Flange mouth with PTFE cover

Way of discharge

Oblique material glass discharge valve, ￠ 80 flange mouth

Stir bar

Painted stainless steel bar, wrapped in PTFE

Our laboratory glass and laboratory equipment for all independent research and development, according to the actual requirements of customers tailored.
